DIMENSIONS
Quality
Available in S235JR according EN10025 with matching 3.1 MTC.
Available from stock in small, medium and large size sheets, from 2mm up to 35mm thickness.
Small size sheets | |
| Dimensions (mm) | Weight kg p/m² |
| 2000 x 1000 x 2 | 16 |
| 2000 x 1000 x 3 | 24 |
| 2000 x 1000 x 4 | 32 |
| 2000 x 1000 x 5 | 40 |
| 2000 x 1000 x 6 | 48 |
| 2000 x 1000 x 8 | 64 |
| 2000 x 1000 x 10 | 80 |
| 2000 x 1000 x 12 | 96 |
| 2000 x 1000 x 15 | 120 |
| 2000 x 1000 x 20 | 160 |
| 2000 x 1000 x 25 | 200 |
| 2000 x 1000 x 30 | 240 |
| 2000 x 1000 x 35 | 280 |
Medium size sheets | |
| Dimensions (mm) | Weight kg p/m² |
| 2500 x 1250 x 2 | 16 |
| 2500 x 1250 x 3 | 24 |
| 2500 x 1250 x 4 | 32 |
| 2500 x 1250 x 5 | 40 |
| 2500 x 1250 x 6 | 48 |
| 2500 x 1250 x 8 | 64 |
| 2500 x 1250 x 10 | 80 |
| 2500 x 1250 x 12 | 96 |
| 2500 x 1250 x 15 | 120 |
| 2500 x 1250 x 20 | 160 |
| 2500 x 1250 x 25 | 200 |
| 2500 x 1250 x 30 | 240 |
| 2500 x 1250 x 35 | 280 |
Large size sheets | |
| Dimensions (mm) | Weight kg p/m² |
| 3000 x 1500 x 2 | 16 |
| 3000 x 1500 x 3 | 24 |
| 3000 x 1500 x 4 | 32 |
| 3000 x 1500 x 5 | 40 |
| 3000 x 1500 x 6 | 48 |
| 3000 x 1500 x 8 | 64 |
| 3000 x 1500 x 10 | 80 |
| 3000 x 1500 x 12 | 96 |
| 3000 x 1500 x 15 | 120 |
| 3000 x 1500 x 20 | 160 |
| 3000 x 1500 x 25 | 200 |
| 3000 x 1500 x 30 | 240 |
| 3000 x 1500 x 35 | 280 |
